[Fig. 7-2] Pattern editing screen

7-1. Program pattern setting

●Itisascreentosetthesegmentdependingonthepatternnumber.

●Referto[7-4Timesignaloperation]fortimesignalsetting.

●Pleaserefertothe[7-5Standbyoperation]tofindthingsaboutthestandbyoperation.

①

②

③

④

⑤

Inputthepatternnumberforsegmentsetting

Settingthestartconditionforprogramoperation.

●

NOWPV:ItstartsfromthepresentPVforpresentsetvalueSPin

startingofprogramoperationandprogressedtothesettime(TM1)

forcurrentlysetvalue(SP1)insegment(SEG1)

●

TEMPSSP:Incaseofstartingtheprogramoperation,thepresent

setvalue(SP)isstartedfromtemperatureSSPandprogressesto

thesettime(TM1)forcurrentlysetvalue1(SP1)insegment1(SEG1).

●

HUMISSP :ItstartsfromthesetSSPforpresentsetvalue(SP)in

startingofprogramoperationandprogressedtothesettime(TM1)

forcurrentlysetvalue1(SP1)insegment1(SEG1).

Itsetsthetemperaturesetvalueofsegmenttobeoperated.

Itsetsthehumiditysetvalueofsegmenttobeoperated.

Settingthetimeofsegmenttobeoperated.

Itsetsthetimesignalofthesegmenttobeoperated.

●

4timesignalscanbesetforeachsegmentandeachtimesignal

issetbyselectionfrom18typesoftimesignal.

●

Referto[7-4Timesignaloperation]

⑥

Samwon Tech TEMI1000 Series User Manual
