07. Program setting
[Fig. 7-3] Pattern and segment repetition Setting screen
7-2. Pattern repetition setting
●Itisascreentosetthefunctionforentireorpartialrepetitionofsetpattern.
●Theoperationmethodinpatternoperationterminationcanbeset.
⑤
⑥
⑦
⑧
①
②
③
④
Itsetsthepatternnumbertoperformtherepetitiveoperation.
Itsetstherepetitionoperationfrequencyofthesetpattern.
Itsetsthepatternnumberforrepetitiveoperationinterminationof
setpatternoperation.
Itsetsthesegmenttostartthepartialrepetitiveoperationoutof
thesetpatterns.
Itsetsthesegmenttoterminatethepartialrepetitiveoperationoutof
thesetpatterns.
Itsetstherepetitionfrequencyofthepartialrepetitiveoperationoutof
thesetpatterns.
Itdisplaystheexperimentnameofthesetpattern.
●
 Thechangeoftheexperimentnamecanbechangedin[7-6Experimentnamesetting]
●
Thechangeisimpossibleasitisonlyforreading.
Itdecidesthenextoperationwhenthesetpatternoperationisfinished.
●
Operationstop:Thepatternterminationsignalisgeneratedandthe
operationstateisinprogramstop.
●
 SEGhold:Itisoperatedinlastoperationsetvalueandholdstateismaintained.
●
 Connectionoperation:Thepatternsetintheconnectionpatternisoperated.
Parameter Initial valueSetting range Unit
PatternNo.
Repetitionfrequency
Connectionpattern
Operationinpatterntermination
Startsegmentforrepetitionsetting1~4
Terminationsegmentforrepetitionsetting1~4
Repetitionfrequencyforrepetitionsetting1~4
1~120
0(Indefiniterepetition)~999
1~120
Operationstop,SEGhold,Continuationoperation
0~99
0~99
0~99
ABS
ABS
ABS
ABS
ABS
ABS
ABS
1
1
1
Operationstop
0
0
0
