Samwon Tech TEMI1000 Series User Manual

SettingtheitemsanddirectionoftransmittinginSDcardandTEMI1000
●
PTN:Downloadoruploadthesetpatternin
[7-1Programpatternsetting]
●
PAR A:Downloadoruploadthesetparameter
●
ALL:Downloadoruploadthepatternandparameter
●
Download:Transmittingtheselectedtransmittingitemsoutof
theinternaldatainTEMI1000toSDcard
●
Upload:Transmittingtheselectedtransmittingitemsoutofthe
saveddatainTEMI1000toSDcard
ItdisplaysthecurrentcapacityofSDcard
●
ItdisplayswhentheSDcardisinsertedonly
WhenthedataisnotinrecordingtoSDcard,isactivatedand
downloadanduploadarepossiblewhenistouchedby.
①
②
③
48
2
3
1
6-4. Memory save setting
●ItisascreentosetthetransmittingofpatternandparametertoSDcard.
●ItisascreendisplayedinSDcardoptiononly.
[Fig. 6-10] Graph&Save setting screen 4
Parameter Initial valueSetting range Unit
Transmittingitem
Transmittingdirection
Pattern,PARA,ALL
Download,Upload
ABS
ABS
Pattern
Download
