Samwon Tech TEMI1000 Series - Basic Operation Flow Chart

01. Operation and setting
4
Thisproductisprogrammablecontrollerdesignedwithdialoguestyletouchscreeneasy-to-usefortheusers.
1-1. Basic operation flow chart
●Thelogoscreenandtheinitialscreenaredisplayedsequentiallywhentheelectricpowerisswitched“ON”
afterinstallationoftheproductanditconvertstotheprogramstationaryscreen.
●Ittakesabout20secondsforscreenloading
●Whenbuttonistouchedatthetopoftheprogramstationaryscreen,itconvertstothemainscreen.
●Referto[13.Systeminitialsetting]in[Installationmanual]forchangeintheinitialscreen.
Logoscreen Initialscreen Stationaryoperationstillscreen(TEMI1500) Mainscreen(TEMI1500)
Mainscreen(TEMI1300/1900WIDE) Stationaryoperationstillscreen(TEMI1300/1900WIDE)
