6-3. Presented value (PV) graph saving setting
●Thisscreenistosetthedisplayrangeandsamplingtimewhicharenecessaryforgraphrecordingin
[3-1(5)Stationaryoperation3operationscreen]and[3-2(5)Programoperation3operationscreen].
[Fig. 6-9] Graph&Save setting screen 3
3
4
1
2
SettingthePVgraphsavingperiod
●
ItisnotchangeableduringPVgraphsaving
●
Savingabout90daysispossiblewhensamplingtimeissetin
1minuteinsavingintointernalmemory.
SettingY/Nforsavingthedataintotheinternalmemory.
●
 Auto:SavingthedatainsynchronizedwithOperation/Stopautomatically
●
Manual:SavingthedatabythesavingkeyintheOperation
screen3manually
●
Thesaveddataintotheinternalmeemoryarepreservedwhen
theelectricpoweris"ON/OFF"
SettingthedisplayrangeofTemperaturegraph
SettingthedisplayrangeofHumiditygraph
①
②
③
④
Parameter Initial valueSetting range Unit
Recordingcycle
Savingoperationsetting
Tempgraphdisplayupperlimit
Tempgraphdisplaylowerlimit
Humigraphdisplayupperlimit
Humigraphdisplaylowerlimit
1Sec,2Sec,5Sec,10Sec,20Sec,30Sec,1Min
Auto,Manual
T.EU(-2.50~102.50%)
(Tempgraphdisplaylowerlimit<Tempgraphdisplayupperlimit)
H.EU(0.0~100.0%)
(Humigraphdisplaylowerlimit<Humigraphdisplayupperlimit)
ABS
ABS
T.EU
T.EU
H.EU
H.EU
1Sec
Auto
T.EU(100.00%)
T.EU(0.0%)
H.EU(100.0%)
H.EU(0.0%)
06. Setting graph display and save
