51
07. Program setting
[Fig. 7-1] Program setting screen
2
3
4
5
6
1
①
②
③
Movingtothepatterneditingscreen
Movingtothescreenforrepetitivesettingofpatternandsegment
Movingtothescreenforsettingpatterncopyanddeletion
Movingtothescreenfortimesignalsetting
Movingtothescreenforsettingthestandbyscreen
Movingtothescreenforexperimentname
④
⑤
⑥
●Itconvertsto[Fig.7-1Programsettingscreen]whentheprogramsettingbuttonistouchedbyin[Fig.2-1Mainscreen].
●Itisascreengrouptosettheparametersrelatedtotheprogramoperation.
