SAMWONTECH
4th Edition of TEMI880 IM : Jan. 29. 2007 Page 81 / 119
3. Parameter Setting Table
▶ This tables display setting range and initial value of the each parameters.
2.7 Set Operation
Symbol Parameter Setting Range Unit Init. Value
OPER. MODE OPERATION MODE PROG, FIX ABS PROG
POWER MODE POWER MODE STOP, COLD, HOT ABS STOP
FUZZY SELECT FUZZY SELECT OFF, ON ABS OFF
KEY LOCK KEY LOCK OFF, ON ABS OFF
LIGHT OFF LIGHT OFF 0~99 ABS OFF
OPER. HOUR OPERATION HOUR 0~9999 ABS 0
OPER. MIN
OPERATION
MINUTE
0~59 ABS 0
TIME MODE TIME MODE OFF, ON ABS OFF
TEMP SLOPE TEMP SLOPE T.EUS(0~100%)/MIN T.EUS/MIN T.EUS(0%)/MIN
HUMI SLOPE HUMI SLOPE H.EUS(0~100%)/MIN H.EUS/MIN H.EUS(0%)/MIN
2.8 Set Reservation
Symbol Parameter Setting Range Unit Init. Value
Y YEAR 0~99 ABS 01
M MONTH 1~12 ABS 01
D DAY 1~31 ABS 01
H HOUR 0~23 ABS 01
M MINUTE 0~59 ABS 00
RESERVE MODE RESERVE MODE OFF, ON ABS OFF
2.9 Set Graph and Graph Data Storage
Symbol Parameter Setting Range Unit Init. Value
PTNO PATTERN NUMBER 0~120 ABS 0
TEMP SP TEMP SP DISPLAY OFF, ON ABS ON
HUMI SP HUMI SP DISPLAY OFF, ON ABS ON
OPER. MODE OPERATION MODE STOP, RUN ABS STOP
TIME UNIT TIME UNIT SEC, MIN ABS SEC
SAMPLING TIME SAMPLING TIME 1~59 ABS 5
BACK UP SELECT BACK UP PTN, PARA, ALL ABS PTN
DIRECT SELECT DIRECT DNLOAD, UPLOAD ABS DNLOAD
To Next Page
