4.3 Communication Command
4.3.1 The composition of communication command
▶ It is basic communication command structure between upper-level computer and TEMI880.
○
1
○
2
○
3
○
4
○
5
○
6
○
7
○
8
S
T
X
Address Command
,
Data by Command rule SUM
C
R
L
F
○
1 STX(Start of Text)
This code indicates the start of a command string.
○
2 Address
Communication address to identify the instruments.
○
3 Command
Specify the command from an upper device (See 4.3.2~4.3.9).
○
4 ‘,’(Separation character)
Character for separating command and data by ‘,’.
○
5 Data
Data by Command rule.
○
6 Check Sum
It is only using when the protocol is “PCL1”.(basic protocol + check sum)
○
7,
○
8 CR,LF
This control code indicates the end of a command.
