Samwon Tech TEMI880 User Manual

SAMWONTECH
4th Edition of TEMI880 IM : Jan. 29. 2007 Page 83 / 119
2.10.6 Set Pattern Name
Symbol Parameter Setting Range Unit Init. Value
PTNO 1~120
PATTERN NAME
1~120
0~9, A~Z,
Special character
(Max 10 characters)
ABS
PROG PT001
~ PROG PT120
2.11 Select Screen
Symbol Parameter Setting Range Unit Init. Value
TUNING KEY
TUNING KEY
DISPLAY BUTTON
HIDE, DISP ABS DISP
CONTRAST SET
CONTRAST GROUP
SET
DARK, NOR, LIGHT ABS NOR
2.12.1.1 Set Temperature Input
Symbol Parameter Setting Range Unit Init. Value
SENSOR TYPE
TEMP SENSOR
TYPE
PT_1(-90.00~200.00)
PT_2(-100.0~300.00)
DCV(-1.000~2.000)
ABS PT_1
TEMP RH TEMP RANGE HIGH T.EU T.EU(100%)
TEMP RL TEMP RANGE LOW
T.EU(0~100%)
TEMP RL < TEMP RH
T.EU T.EU(0%)
TEMP BIAS TEMP BIAS T.EUS(-105~105%) T.EUS T.EUS(0%)
DISPLAY FILTER DISPLAY FILTER OFF, 1~120 ABS OFF
FILTER TIME TEMP FILTER TIME 0~120 SEC ABS 0
TEMP SH TEMP SCALE HIGH ABS 200.0
TEMP SL TEMP SCALE LOW
-100.0~200.0
TEMP SL < TEMP SH
ABS -100.0
2.12.1.2 Set Humidity Input
Symbol Parameter Setting Range Unit Init. Value
SENSOR TYPE
HUMI SENSOR
TYPE
PT(-10.0~110.0)
DCV(1.000~5.000)
ABS PT
HUMI RH HUMI RANGE HIGH H.EU H.EU(100%)
HUMI RL HUMI RANGE LOW
H.EU(0~100%)
HUMI RL < HUMI RH
H.EU H.EU(0%)
HUMI BIAS HUMI BIAS H.EUS(-20~20%) H.EUS H.EUS(0%)
FILTER TIME HUMI FILTER TIME 0~120 SEC ABS 0
HUMI SH HUMI SCALE HIGH ABS 100.0
HUMI SL HUMI SCALE LOW
0.0~100.0
HUMI SL < HUMI SH
ABS 0.0
2.12.1.3 Display Input
Symbol Parameter Setting Range Unit Init. Value
WET ADJUST WET TEMP ADJUST H.EUS(-105~105%) H.EUS H.EUS(0%)
DRY LIMIT RH
DRY TEMP
LIMIT HIGH
ABS 100.0
DRY LIMIT RL
DRY TEMP
LIMIT LOW
0.0~100.0
DRY LIMIT RL
< DRY LIMIT RH
ABS 0.0
