2.12.4.2 Set PID Group(PID1~PID9)
Symbol Parameter Setting Range Unit Init. Value
P
PROPORTIONAL
BAND
0.1~999.9 ABS 5.0
I INTEGRAL TIME 0~6000 ABS 120
D DERIVATIVE TIME 0~6000 ABS 30
OH
OUTPUT
LIMIT HIGH
ABS 100.0
OL
OUTPUT
LIMIT LOW
0.0~100.0
OL < OH
ABS 0.0
2.12.5 Set DO CONFIG
Symbol Parameter Setting Range Unit Init. Value
IS1~IS8 RELAY
INNER SIGNAL1~8
RELAY
0(OFF)~20 ABS 0
TS1~TS4 RELAY
TIME SIGNAL1~4
RELAY
0(OFF)~20 ABS 0
AL1~AL4 RELAY
ALARM SIGNAL1~4
RELAY
0(OFF)~20 ABS 0
T1~T4 RELAY
ON/OFF
SIGNAL1~4 REALY
0(OFF)~20 ABS 0
T1~T4 CPARA
ON/OFF
SIGNAL1~4 DELAY
00.00~99.59
(MIN.SEC)
ABS 00.00
T.RUN RELAY
TEMP RUN
RELAY
0(OFF)~20 ABS 0
T.RUN CPARA
TEMP RUN
DELAY
0~999 SEC ABS 0
H.RUN RELAY
HUMI RUN
RELAY
0(OFF)~20 ABS 0
H.RUN CPARA
HUMI RUN
DELAY
0~999 SEC ABS 0
T.UP RELAY
TEMP UP
RELAY
0(OFF)~20 ABS 0
T.UP CPARA
TEMP UP
RANGE
T.EUS(-10~10%) T.EUS T.EUS(0%)
T.SK RELAY
TEMP SOAK
RELAY
0(OFF)~20 ABS 0
T.SK CPARA
TEMP SOAK
TIME
0~999 MIN ABS 0
T.DN RELAY
TEMP DOWN
RELAY
0(OFF)~20 ABS 0
H.DN CPARA
HUMI DOWN
RANGE
H.EUS(-10~10%) H.EUS H.EUS(0%)
H.UP RELAY
HUMI UP
RELAY
0(OFF)~20 ABS 0
