s05mdl1sm-REV0708 Model S05 Metallic Page 15
1 031-191-000 Air Valve Assembly (Integral Muffl er) 1
031-167-000 Air Valve Assembly (w/ stroke Indicator Pins) 1
031-186-000 Air Valve Assembly 1
031-169-000 Air Valve Assembly
(Stroke Indicator & Optional Muffl ers) 1
031-186-003 Air Valve Assembly w/ Stainless Steel hardware 1
031-186-002 Air Valve (High Temperature) 1
031-191-002 Air Valve (High Temperature With Integral Muffl ers) 1
031-191-003 Air Valve Assembly (Stainless Steel Hardware) 1
2 050-022-600 Ball, Check 4
050-027-354 Ball, Check 4
050-027-356 Ball, Check 4
050-027-360 Ball, Check 4
050-027-364 Ball, Check 4
050-027-365 Ball, Check 4
3 095-116-000 Pilot Valve Assembly 1
4 114-023-157 Bracket, Intermediate 1
5 115-152-151 Bracket, Mounting (Aluminum) 2
6 132-034-360 Bumper, Diaphragm 2
7 135-036-506 Bushing, Plunger 2
8 165-110-157 Cap, Air Inlet 1
9 170-044-115 Capscrew, Hex 5/16-18 X 1.00 8
170-044-330 Capscrew, Hex 5/16-18 X 1.00 8
10 170-045-115 Capscrew, Hex 5/16-18 X 1.25 (alum) 40
170-045-330 Capscrew, Hex 5/16-18 X 1.25 (alum) 40
170-045-115 Capscrew, Hex 5/16-18 x 1.25 (ss) 24
170-045-330 Capscrew, Hex 5/16-18 x 1.25 (ss) 24
11 171-017-115 Capscrew, Flat Socket Head 1/4-20 x .50 4
171-017-330 Capscrew, Flat Socket Head 1/4-20 x .50 4
12 171-076-115 Capscrew, Flanged 1/4- 20 x 75 4
171-076-330 Capscrew, Flanged 1/4-20 x 75 4
13 171-077-115 Capscrew, Flanged 1/4-20 x 1.50 4
171-077-330 Capscrew, Flanged 1/4-20 x 1.50 4
14 196-171-110 Chamber, Outer 2
196-171-112 Chamber, Outer 2
196-171-157 Chamber, Outer 2
15 286-095-354 Diaphragm 2
286-095-356 Diaphragm 2
286-095-360 Diaphragm 2
286-095-363 Diaphragm 2
286-095-364 Diaphragm 2
286-095-365 Diaphragm 2
286-116-000 Diaphragm, One-Piece Bonded 2
16 286-096-600 Diaphragm, Overlay 2
17 312-110-157 Elbow, Suction 2
18 312-111-157 Elbow, Discharge 2
19 360-099-360 Gasket, Spacer (used TPE Diaphragms only) 2
20 360-100-379 Gasket, Air Inlet 1
21 360-102-360 Gasket, Air Valve 1
22 360-108-360 Gasket, Pilot Valve 1
23 518-157-157 Manifold (see item 29) 2
518-157-157E Manifold BSP Tapered (see item 29) 2
24 518-158-110 Manifold, Suction 1
518-158-110E Manifold, Suction BSP Tapered 1
518-158-112 Manifold, Suction 1
518-158-112E Manifold, Suction BSP Tapered 1
25 518-159-110 Manifold, Discharge 1
518-159-110E Manifold, Discharge BSP Tapered 1
518-159-112 Manifold, Discharge 1
518-159-112E Manifold, Discharge BSP Tapered 1
26 530-035-000 Metal Muffl er 1
27 545-004-115 Nut, Hex Flanged 5/16-18 (Aluminum) 24
545-004-330 Nut, Hex Flanged 5/16-18 (Aluminum) 24
545-004-115 Nut, Hex Flanged 5/16-18 (Stainless Steel) 8
545-004-330 Nut, Hex Flanged 5/16-18 (Stainless Steel) 8
28 560-001-360 O-ring 2
29 560-083-360 O-ring (Aluminum Manifold) 4
560-083-363 O-ring (Aluminum Manifold) 4
560-083-364 O-ring (Aluminum Manifold) 4
560-083-365 O-ring (Aluminum Manifold) 4
720-064-600 Seal (Aluminum Manifold) 4
560-083-360 O-ring (metallic seats only) 8
560-083-363 O-ring (metallic seats only) 8
560-083-364 O-ring (metallic seats only) 8
560-083-365 O-ring (metallic seats only) 8
560-083-611 O-ring (metallic seats only) 8
30 612-091-110 Plate, Outer Diaphragm 2
612-091-112 Plate, Outer Diaphragm 2
612-091-157 Plate, Outer Diaphragm 2
31 612-177-330 Plate, Inner Diaphragm 2
612-221-330 Plate, Inner Diaphragm (One-Piece Bonded Only) 2
32 620-019-115 Plunger, Actuator 2
33 675-042-115 Ring, Retainer 1
34 685-056-120 Rod, Diaphragm 2
35 720-012-360 Seal, U-Cup Shaft 4
36 722-094-080 Seat, Check Valve (item 29 required) 4
722-094-110 Seat, Check Valve (item 29 required) 4
722-094-150 Seat, Check Valve (item 29 required) 4
722-094-550 Seat, Check Valve 4
722-094-600 Seat, Check Valve 4
37 900-004-115 5/16 Lock Washer (Aluminum) 48
900-004-330 5/16 Lock Washer (Aluminum) 48
900-004-115 5/16 Lock Washer (Stainless Steel) 32
900-004-330 5/16 Lock Washer (Stainless Steel) 32
ITEM PART NUMBER DESCRIPTION QTY
ITEM PART NUMBER DESCRIPTION QTY
Composite Repair Parts List
NOTE: See Pages 16 and 18 For Full Explanation of Air Valve Options.
Note: Atex Compliant
