s05mdl1sm-REV0708 Model S05 Metallic Page 27
Optional Muffl er Confi gurations, Drawing
OPTION 0
530-031-550 Integral Muffl er uses
(1) Cap and (4) 706-027-115 Machine
Screw to hold it in place.
OPTION 1
530-024-000 Sound Dampening Muffl er
screws directly into the Air Valve body.
This muffl er is equipped with a porous
plastic element.
OPTION 2
530-023-000 Mesh Muffl er screws
directly into the Air Valve Body. This
muffl er is equipped with a metal element.
OPTION 6
530-035-000 Metal Muffl er screws
directly into the Air Body.
Option 1 and 2
Option 6
Option 0
Note: ATEX compliant
