s05mdl1sm-REV0708 Model S05 Metallic Page 30
SINGLE PORT SUCTION REPAIR PARTS LIST
ITEM PART NO. DESCRIPTION QTY
10* 170-045-115 Capscrew, Hex 5/16-18 x 1.25 32
170-045-330 Capscrew, Hex 5/16-18 x 1.25 32
18* 312-111-157E Elbow, Discharge BSP (tapered) 2
(repalces 312-111-157)
312-111-157N Elbow, Discharge 1/2" NPT 2
(replaces 312-111-157)
23* 518-157-157 Manifold BSPT (suction position only) 1
518-157-157E Manifold NPT (suction position only) 1
27* 545-004-115 Nut, Hex 5/16-18 28
545-004-330 Nut, Hex 5/16-18 28
29* 560-083-360 O-ring (Alum Manifold) 2
560-083-363 O-ring (Alum Manifold) 2
560-083-364 O-ring (Alum Manifold) 2
560-083-365 O-ring (Alum Manifold) 2
720-064-600 Seal (Alum Manifold) 2
37* 900-004-115 Lock Washer 40
900-004-330 Lock Washer 40
SINGLE PORT DISCHARGE REPAIR PARTS LIST
10* 170-045-115 Capscrew, Hex 5/16-18 X 1.25 32
170-045-330 Capscrew, Hex 5/16-18 X 1.25 32
17* 312-110-157E Elbow, Suction BSP (tapered) 2
(replaces 312-110-157)
312-110-157N Elbow, Suction 1/2" NPT 2
(replaces 312-110-157)
23* 518-157-157 Manifold BSPT (discharge position only) 1
518-157-157E Manifold NPT (discharge position only) 1
27* 545-004-115 Nut, Hex 5/16-18 28
545-004-330 Nut, Hex 5/16-18 28
29* 560-083-360 O-ring (Alum Manifold) 2
560-083-363 O-ring (Alum Manifold) 2
560-083-364 O-ring (Alum Manifold) 2
560-083-365 O-ring (Alum Manifold) 2
720-064-600 Seal (Alum Manifold) 2
37* 900-004-115 Lock Washer 40
900-004-330 Lock Washer 40
*
Quantities change from Composite Repair Parts List.
DUAL PORT SUCTION AND DISCHARGE REPAIR PARTS LIST
10* 170-045-115 Capscrew, Hex 5/16-18 X 1.25 24
170-045-330 Capscrew, Hex 5/16-18 X 1.25 24
17* 312-110-157E Elbow, Suction BSP (tapered) 2
(replaces 312-110-157)
312-110-157N Elbow, Suction 1/2" NPT 2
(replaces 312-110-157)
18* 312-111-157E Elbow, Discharge BSP (tapered) 2
(replaces 312-111-157)
312-111-157N Elbow, Discharge 1/2" NPT 2
(replaces 312-111-157)
23* 518-157-157 Manifold (not required) 0
27* 545-004-115 Nut, Hex 5/16-18 20
545-004-330 Nut, Hex 5/16-18 20
29* 560-083-360 O-ring (Alum Manifold) (not required) 0
560-083-363 O-ring (Alum Manifold) (not required) 0
560-083-364 O-ring (Alum Manifold) (none required) 0
560-083-365 O-ring (Alum Manifold) (none required) 0
720-064-600 Seal (Alum Manifold) (none required) 0
37* 900-004-115 Lock Washer 32
900-004-330 Lock Washer 32
