Sandpiper S07 - Composite Repair Parts List

s07nmdl1sm-rev0817
sandpi p erpump .com
10 • Model S07 Non-Metallic
Composite Repair Parts List
1 031-166-000 Air Valve Assembly (Integral Mufer) 1
031-166-002 Air Valve Assembly (with PTFE Coated Hardware) 1
031-167-000 Air Valve Assembly (with stroke Indicator Pins) 1
031-167-002 Air Valve Assembly (with Stroke Indicator Pins and 1
PTFE Coated Hardware)
031-168-000 Air Valve Assembly (Optional Mufers) 1
031-169-000 Air Valve Assembly (Stroke Indicator & 1
Optional Mufers)
031-176-000 Air Valve (High Temperature) 1
031-177-000 Air Valve (High Temperature With Mufers) 1
2 050-028-354 Ball, Check Valve 4
050-028-357 Ball, Check Valve 4
050-028-600 Ball, Check Valve 4
3 095-091-000 Pilot Valve Assembly 1
095-091-003 Pilot Valve Assembly (Conductive Acetal) 1
4 114-023-551 Bracket, Intermediate 1
5 115-141-115 Bracket, Mounting 2
6 132-034-360 Bumper, Diaphragm 2
7 135-036-506 Bushing, Plunger 2
8 165-110-551 Cap, Air Inlet 1
9 171-062-115 Capscrew, Flanged 5/16-18 x 1.00 8
171-062-308 Capscrew, Flanged 5/16-18 x 1.00 8
171-075-115 Capscrew, Flanged 5/16-18 x 1.00 4
10 171-063-115 Capscrew, Flanged 5/16-18 x 1.25 24
171-063-308 Capscrew, Flanged 5/16-18 x 1.25 24
11 171-064-115 Capscrew, Flanged 5/16-18 x 1.50 12
171-064-308 Capscrew, Flanged 5/16-18 x 1.50 12
12 171-066-115 Capscrew, Flanged 1/4-20 x 1.25 8
171-066-308 Capscrew, Flanged 1/4-20 x 1.25 8
13 196-162-520 Chamber, Outer 2
196-162-542 Chamber, Outer 2
196-162-552 Chamber, Outer 2
14 286-095-354 Diaphragm 2
286-095-360 Diaphragm 2
286-116-000 Diaphragm, One-Piece Bonded 2
15 286-096-600 Diaphragm, Overlay 2
16 312-107-520 Elbow 4
312-107-542 Elbow 4
312-107-552 Elbow 4
17 360-099-360 Gasket, Spacer (Use with TPE Diaphragms Only) 2
18 360-100-360 Gasket, Air Inlet 1
19 360-101-360 Gasket, Pilot Valve 1
20 360-102-360 Gasket, Air Valve 1
21 518-139-520 Manifold (NPT) 2
518-139-520E Manifold (BSPT), tapered 2
518-139-542 Manifold (NPT) 2
518-139-542E Manifold (BSPT), tapered 2
518-139-552 Manifold (NPT) 2
518-139-552E Manifold (BSPT), tapered 2
23 544-005-115 Nut, Flanged 5/16-18 36
544-005-308 Nut, Flanged 5/16-18 36
24 560-001-360 O-ring 2
25 612-091-520 Plate, Outer Diaphragm 2
612-091-542 Plate, Outer Diaphragm 2
612-091-552 Plate, Outer Diaphragm 2
26 612-177-330 Plate, Inner Diaphragm 2
612-221-330 Plate, Inner (use with 2 One-Piece
Bonded Diaphragm Only) 2
27 620-019-115 Plunger, Actuator 2
28 670-050-520 Retainer, Ball 4
670-050-542 Retainer, Ball 4
670-050-552 Retainer, Ball 4
29 675-042-115 Ring, Retaining 2
30 685-056-120 Rod, Diaphragm 1
31 720-012-360 Seal, Diaphragm Rod 2
32 720-046-600 Seal, Manifold 4
33 720-051-600 Seal, Check Valve Retainer 8
34 722-081-520 Seat, Check Valve 4
722-081-542 Seat, Check Valve 4
722-081-552 Seat, Check Valve 4
NOT SHOWN:
535-069-000 Nameplate
ITEM PART NUMBER DESCRIPTION QTY
3: EXP VIEW
