Sandpiper S07 - Explanation of Nomenclature

s07nmdl1sm-rev0817
sandpi p erpump .com
1 • Model S07 Non-Metallic
Explanation of Pump Nomenclature
Your Serial #: (ll in from pump nameplate) _____________________________________
Pump Pump Check Design Wetted Diaphragm/ Check Valve Non-Wetted Porting Pump Pump Kit
Brand Size Valve Level Material Check Valve Seat Material Options Style Options Options
S XX X X X X X X X X X XX
Model #:
S
__ ____ __ __ __ __ __ __ __ __ __ ____
(ll in from pump
nameplate)
Your Model #:
IEC EEX m T4
Note: Pump models equipped with these
explosion-proof solenoid kit options E1, E3,
E5, E7, E8 or E9, are certied and approved
by the above agencies. They are NOT ATEX
compliant.
Pump Brand
S SANDPIPER
®
Pump Size
07 3/4"
Check Valve Type
B Ball
T Tihedral
Design Level
1 Design Level 1
Wetted Material
K PVDF
N Nylon
P Polypropylene
Diaphragm/Check Valve Materials
1 Santoprene/Santoprene
2 Virgin PTFE-Santoprene
Backup/Virgin PTFE
7 Santoprene/Nitrile
8 Virgin PTFE-Santoprene
Backup/FKM
B Nitrile/Nitrile
U Polyurethane/Polyurethane
Z One-Piece Bonded/PTFE
Check Valve Seat
K PVDF
N Nylon
P Polypropylene
Non-Wetted Material Options
P Polypropylene
I Polypropylene with PTFE Hardware
Porting Options
N NPT Threads
1 Dual Porting (NPT)
2 Top Dual Porting (NPT)
3 Bottom Dual Porting (NPT)
B BSP Threads (tapered)
4 Dual Porting (BSP) (tapered)
5 Top Dual Porting (BSP) (tapered)
6 Bottom Dual Porting (BSP) (tapered)
Pump Style
S Standard
Pump Options
0 None
6 Metal Mufer
Kit Options
00. None
P0. 10-30VDC Pulse Output Kit
P1. Intrinsically-Safe
5-30VDC,110/120VAC, 220/240VAC
Pulse Output Kit
P2. 110/120 or 220/240VAC Pulse Output
Kit
E0. Solenoid Kit w/24VDC Coil
E1. Solenoid Kit 24VDC Explosion-Proof
Coil
E2. Solenoid Kit w/24VAC/12VDC Coil
E3. Solenoid Kit w/12VDC Explosion-Proof Coil
E4. Solenoid Kit w/110VAC Coil
E5. Solenoid Kit w/110VAC 60 Hz Explosion-
Proof Coil
E6. Solenoid Kit w/220VAC Coil
E7. Solenoid Kit w/220VAC 60 Hz Explosion-
Proof Coil
E8. Solenoid Kit w/110VAC 50 Hz Explosion-
Proof Coil
E9. Solenoid Kit w/230VAC 50 Hz Explosion-
Proof Coil
SP Stroke Indicator Pins
1: PUMP SPECS
