Polarization Control Unit PCU-110
3-1
Panel Description
3
Figure 3-1.
Front Panel
(1) Power on switch
Switch the unit on and off using the power switch.
(2) Optical input Port
This port is connected with PM ber.
(3) Optical Output Port
This port is connected with SM ber.
(4) SOP display
Displays the current SOP (state of polarization) setting.
3-1 Front Panel
(1)
(2) (3)
(4)
