12
REMOVE THE TV
HEAVY! You may need assistance with this step.
4
12
1 32
14
08
04
04
1. Disconnect all cables from the TV.
2. Remove securement screw
12
.
3. Pull down on the release cord
R
to release the TV.
4. Carefully lift the TV from arm assembly
08
.
R
EXTEND / RETRACT -- ONLY IF NECESSARY
ONLY If needed, adjust the arm tension when you extend or retract your TV, with screw
E
using hex key
13
.
13
13
E
13
TIP:
CAUTION:
Avoid potential personal injury or property damage! DO NOT remove screws
E
, only turn enough for slight adjustment.
E
E
