Sanus BMF320 - Dimensions; Before You Begin; Remove the Stand; Install any Accessories

3
7/16 in.
(11 mm)
16.28
413.4
15.75
400.0
16.40
416.6
18.03
458.0
0.38
9.7
3.94
100.0
3.94
100.0
11.39
289.3
2.59
65.8
0.33
8.4
13.03
331.0
15.93
404.5a
2.46
62.5
OFFSET
20.00
508.1
60.00°
SIMULATED 49"
FLAT SCREEN TV
15°
5°
2.04
51.8
TV INTERFACE
WALL PLATE
FULLY ASSEMBLED MOUNT
TOP VIEW - EXTENDED
TOP VIEW - RETRACTED
SIDE VIEW - EXTENDED
SIDE VIEW - RETRACTED
3-D
Dimensions
BEFORE YOU BEGIN
Remove the stand
from your TV — if attached.
Install any accessories
you may have purchased, if they
requireTV removal prior to assembly.
The TV is removable for future
accessory purchases.
Soft clean surface
Protect the face
of your TV when laying it
down for installation.
