D-1034-143 PC5000a（E）
DRAWING No. PC5000a 07-0812 2040 6010
—
13
—
Note:
Power-up-default reference impedance will be displayed for 1
second before displaying the dBm readings. Press
dBm-
Ω(RANGE)
button momentarily to select different reference
impedance of 4, 8, 16, 32, 50, 75, 93, 110, 125, 135, 150, 200,
250, 300, 500, 600, 800, 900, 1000, up to 1200Ω. The new
impedance value will be saved automatically to the non-volatile
memory as power up default.
