5-2-3 ACmV / DCmV / (AC+DC) mV measurement
1) Applications
ACmV: Voltage of the battery and DC circuit are measured.
DCmV: Voltage of the DC circuit is measured.
(AC+DC) mV: Voltage of the AC component+DC component
is measured.
2) Measuring ranges
1 ranges 500.00mV
3) Measurement procedure
Connect the plug of black test lead to COM terminal and
plug of red test lead to
mV terminal.
Set the function switch to 'mV'.
Press "SELECT" button to toggle ' ' or ' ' or ' '
measurement.
Apply the red and black test pins to the circuit to measure.
For measurement of DCmV, apply the black test pin to
the negative potential side of the circuit to measure and
the red test pin to the positive potential side.
For measurement of ACmV, apply the red and black test
pins to the circuit to measure.
For measurement of (AC+DC)mV, apply the red and
black test pins to the circuit to measure.
The reading of Voltage is shown in the display.
After measurement, release the red and black test pins from
the object measured.
Note:
Press "500000" button to between 50000 count and 500000
count at DCmV.
—
