RANGE Accuracy*
45Hz - 300Hz
500.00mV, 5.0000V, 50.000V,
0.8%rdg + 60dgt
500.00V, 1000.0V
300Hz - 1kHz
500.00mV 0.8%rdg + 40dgt
5.0000V, 50.000V, 500.00V 2.0%rdg + 60dgt
1000.0V 1.0%rdg + 40dgt
1kHz - 20kHz
500.00mV ±1dB**
5.0000V, 50.000V ±2dB**
500.00V ±3dB**
1000.0V Unspec'd
D-1034-143a PC5000（E）
DRAWING No. PC5000a 07-0812 2040 6010
AC & AC+DC Voltage
—
38
—
*From 5% to 10% of range: Accuracy % of reading + 80digit
**From 5% to 10% of range: Accuracy % of reading + 180digit
**From 10% to 15% of range: Accuracy % of reading + 100digit
CMRR:>90dB @ DC to 60Hz, Rs=1kΩ
Input Impedance: 10MΩ, 30pF nominal (80pF nominal for 500mV
range) Residual reading less than 50 digits with
test leads shorted.
dBm
At 600Ω, -11.76dBm to 54.25dBm,
Accuracy: ±0.25dB + 2dgt (@40Hz - 20kHz)
Input Impedance: 10MΩ, 30pF nominal
Selectable reference impedance of 4, 8, 16, 32, 50, 75, 93, 110,
125, 135, 150, 200, 250, 300, 500, 600, 800, 900, 1000, 1200Ω
