Sanwa PC5000a - Page 42

D-1034-143 PC5000a（E）
DRAWING No. PC5000a 07-0812 2040 6010
—
39
—
DC Current
RANGE Accuracy Internal Resistance
500.00µA 0.15%rdg + 20dgt
Approx. 100Ω
5000.0µA 0.1%rdg + 20dgt
50.000mA 0.15%rdg + 10dgt
Approx. 1Ω
500.00mA 0.1%rdg + 20dgt
5.0000A 0.5%rdg + 10dgt
Approx. 0.005Ω
10.000A* 0.5%rdg + 20dgt
*<6A: Continuous measurement is possible. >6A: Cool down DMM
for 3 minutes after the measurement for 1 minute.
AC & AC+DC Current
RANGE Accuracy
Internal Resistance
50Hz ~ 60Hz
500.00µA
Approx. 100Ω
5000.0µA
50.000mA
Approx. 1Ω
500.00mA
1.0%rdg ± 40dgt
5.0000A
Approx. 0.005Ω
10.000A*
40Hz ~ 1KHz
500.00µA
Approx. 100Ω
5000.0µA
50.000mA
Approx. 1Ω
500.00mA
1.0%rdg + 40dgt
5.0000A
Approx. 0.005Ω
10.000A*
*<6A: Continuous measurement is possible. >6A: Cool down DMM
for 3 minutes after the measurement for 1 minute.
DC Loop Current %4~20mA
Accuracy: ±25dgt
4mA = 0% (zero) 20mA = 100% (span) Resolution: 0.01%
