RANGE Accuracy*
50.00nF
0.8%rdg + 3dgt
500.0nF
5.000µF 1.0%rdg + 3dgt
50.00µF 2.0%rdg + 3dgt
500.0µF 3.5%rdg + 5dgt
9999µF 5.0%rdg + 5dgt
Open Circuit Voltage : <1.3VDC (<3VDC for 500Ω range)
Capacitance
RANGE Accuracy
500.00Ω
5.0000kΩ
0.2%rdg + 6dgt
50.000kΩ
500.00kΩ
5.0000MΩ 0.8%rdg + 6dgt
50.000MΩ 2.0%rdg + 6dgt
D-1034-143a PC5000（E）
DRAWING No. PC5000a 07-0812 2040 6010
Ω Ohms
Measurement range of 500.0
µ
F manual range: 50.0 to 500.0
µ
F.
Measurement range of 9999
µ
F manual range: 500 to 9999
µ
F.
*Accuracies with film capacitor or better
Hz Line Level Frequency
V RANGE Sensitivity (Sine RMS) Measurement Range
500mV 0.1V min
10.000Hz ~ 200.00kHz
5V 1V min
50V 10V min
10.000Hz ~ 100.00kHz
500V 100V min
1000V 900V min 10.000Hz ~ 10.000kHz
Accuracy: 0.02%rdg + 4dgt
—
