Sanyo PLC-ET30L Service Manual

-49-
 ●: Adjustment necessary ❍: Check necessary
Adjustments after Parts Replacement
Adjustments
Disassembly / Replaced Parts
LCD/
Prism
Ass’y
Conden-
sor
Lens
Relay
Lens
(OUT)
Polarized
Glass
(POL)
Optical
Filter
(OF)
Integ-
rator
Lens
PBS
Power
Board
Main
Board
Fans
Optical
Adjustment
Optical axis adjustment
● ● ● ● ●
Contrast adjustment
● ● ●
Electrical Adjustments
Fan voltage adjustment
● ● ●
PC-Auto calibration adjustment
●
Video-Auto calibration adjustment
●
480i-Auto calibration adjustment
●
Common voltage adjustment
● ●
White balance adjustments
❍ ❍
Color shading correction adjust-
ments
❍ ❍
Filter calibration adjustment
● ● ●
Read/Write of gamma data
●
Note on the main board replacement
When replacing the main board, take read/write procedure of the gamma adjustment data and color shading cor-
rection data.
The “gamma adjustment data” and “color shading correction data” of each panel have been adjusted precisely at
the factory to match the characteristics of each panel.
When you replace the main board, you need to read out the "gamma adjustment data" and "color shading correc-
tion data" stored in the memory IC on the previous main board and write down them into the memory IC on the new
main board. By this way, the projector is enabled to reproduce the picture which has the properly adjusted gamma
characteristic and color shading correction.
Use "Projector Service Tool" software for Read/Write of the gamma adjustment data and color shading correction
data. This tool also enable to correct the color shading and gamma characteristics.
PROJECTOR SERVICE TOOL v. 4.11
SERVICE PARTS NO.: 610 340 8811

Sanyo PLC-ET30L Specifications

General

Brightness	3000 ANSI Lumens
Resolution	1024 x 768 (XGA)
Contrast Ratio	500:1
Lamp Life	2000 hours (Normal Mode), 3000 hours (Eco Mode)
Display Type	LCD
Display Technology	3LCD
Aspect Ratio	4:3
Projection Size	30 - 300 inches
Input Ports	S-Video
Output Ports	Audio (Mini Jack)
Operating Temperature	5 - 35 °C
