-89-
Troubleshooting
Detection of Power failure
Projector provides a protection circuit to prevent the secondary failure when the power failure, fans failure or tem-
perature failure occurs on the projector. The power failure detection lines "P-FAIL_S5V", "P-FAIL_15V", etc. are con-
nected to the main power supplies and fans. When the failure occurs, IC301<SYSTEM CONTROL> receives an error
information through the power failure detection lines and turns off the signal "LAMP_DC_ON" output from pin 145 of
IC301 to stop the power supply.
The power failure detection signals are sent to IC1801<I/O EXPANDER> and then sent to IC301<SYSTEM CON-
TROL> .
Diagnosis Information of Power Failure
IC1801
Detecting Signal Failure Circuit/Parts
P-FAIL_1.8V 3.3V, 2.5V,1.8V and peripheral circuit on the Main Board
P-FAIL_S5V S5V, S9V, S12 and peripheral circuit on the Main Board
P-FAIL_15V 15V, 9V, 5V and peripheral circuit on the Main Board
P-FAIL_S1.2V S3.3V, S1.2V and peripheral circuit on the Main Board
P-FAIL_S-5V S-5V and peripheral circuit on the Main Board
P-FAIL_PJ PJ-Network Board and peripheral circuit on the Main Board
FAN_SPEED Failure of Fan, FN901, FN902, FN903, FN904, FN905 connected to the Power(DC) Board
Error information table
IC Pin Signal Name Connection Lines Error Information Failue Area
IC1801
61 P-FAIL_1.8V
3.3V_AD, 3.3VA_AD, 3.3VD_AD,
1.8VA_AD, 1.8VD_AD, 3.3VGA,
3.3VPNL, 3.3V, 2.5V, 1.0VGA,
MAIN, 1.8/1.2V
S6V3, S6V2 S6V1 line on
Main
62
P-FAIL_S-5V S-5V MAIN, S-5V S-5V line on Main, AV
63 P-FAIL_S1.2V
S3.3VFP, S1.2VFPGA,
S1.2VFP, S1.2VPA, S1.2VPD,
FPGA, S1.2V S3.3V, S6V3 line on Main
64 P-FAIL_15V
15V_PNL, 15V_LNS,
9V_LNS, 15.5VRE, 5V
MAIN, 15/9/5V
15V_PNL. 15V_LNS,
9V_LNS, 15.5V, 5V line on
Main
65 P-FAIL_S5V
5VPW, S5V, S5V_TEMP,
S9V_AUDIO, S5V_AUDIO
MAIN, S5/S9/S12
S5V_TEMP, S5V_AUDIO,
S5V, S9V_AUDIO, S5VPW
line on Main
66 P-FAIL_PJ
PJ-Network Board, AV
3.3V1, S5V_EXT
PJ_N/AV, 3.3/S5V
PJ-Network Board, 3.3V,
S5V line on AV, Joint
IC7201
103
I
108
FAN_SPEED5
(FAN_MTR5)
I
FAN_SPEED1
(FAN_MTR1)
FAN CONTROL
FAN1, FANLOCK
FAN2, FANLOCK
FAN3, FANLOCK
FAN4, FANLOCK
FAN5, FANLOCK
Fan Control on Power(DC)
FAN1 (FN901)
FAN2 (FN902)
FAN3 (FN903)
FAN4 (FN904)
FAN5 (FN905)
Power failure detection system
To Next Page
