Sanyo PLC-SW30 Service Manual

MP3-SW3000
Electrical Parts List
-62-
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
Q2863 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
Q2864 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
CAPACITOR
C2861 403 164 0204 CERAMIC 0.1U Z 25V
C2862 403 379 6701 CERAMIC 10U K 16V
RESISTOR
R2862 401 105 0504 MT-GLAZE 1K JA 1/16W
R2864 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R2866 401 105 0504 MT-GLAZE 1K JA 1/16W
R2868 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R2869 401 105 4502 MT-GLAZE 390 JA 1/16W
R2872 401 105 6506 MT-GLAZE 680 JA 1/16W
R2874 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R2876 401 105 0504 MT-GLAZE 1K JA 1/16W
R2878 401 105 0504 MT-GLAZE 1K JA 1/16W
R2891 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R6801 401 105 5103 MT-GLAZE 47 JA 1/16W
R6802 401 105 5103 MT-GLAZE 47 JA 1/16W
R6803 401 105 5103 MT-GLAZE 47 JA 1/16W
DIODE
D2861 407 234 6103 LED SML-310YT-K-T86
407 234 4000 LED SML-310YT-L-T86
407 234 4109 LED SML-310YT-M-T86
D2862 407 234 3805 LED SML-310LT-M-T86
407 234 3904 LED SML-310LT-N-T86
D2863 407 222 4807 LED SML-521MUW T86
D2866 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D2867 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D2868 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D2869 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D2871 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D2872 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D6801 407 149 0807 DIODE 1SS355-TE-17
D6802 407 149 0807 DIODE 1SS355-TE-17
D6803 407 149 0807 DIODE 1SS355-TE-17
D6804 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D6806 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D6807 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D6808 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D6809 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
D6811 407 223 1102 ZENER DIODE 02DZ6.2Y(TPH3
MISCELLANEOUS
SW6801 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6802 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6804 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6806 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6807 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6808 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6809 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6811 645 026 2791 SWITCH,PUSH 1P-1TX1
610 308 1021 ASSY,PWB,FILTER -MP3A
CAPACITOR
!C601 404 081 4702 MT-POLYEST 0.22U M 275V
!C603 404 081 4702 MT-POLYEST 0.22U M 275V
!C604 404 081 4702 MT-POLYEST 0.22U M 275V
!C606 404 073 4505 CERAMIC 2200P K 250V
RESISTOR
R601 401 008 8607 CARBON 220K JA 1/2W
VARIABLE RESISTOR
!VA601 408 018 9808 VARISTOR ENC471D-14AS
COIL
!L601 645 041 4961 LINE FILTER
!L602 645 041 4961 LINE FILTER
MISCELLANEOUS
!F601 423 022 2102 FUSE 250V 4A
F601A 645 006 4760 HOLDER,FUSE
F601B 645 006 4760 HOLDER,FUSE
!K601 645 055 6647 SOCKET,INLET AC 3P
610 308 1038 ASSY,PWB,SW-MP3A
MISCELLANEOUS
SW8801 645 063 5175 SWITCH,PUSH 2P-2TX3
SW BOARD
FILTER BOARD
Key No. Part No. Description Key No. Part No. Description

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
