-39-
■ Waveforms
VIDEO-IN <TP103, IC101-75> Analog H-SYNC <TPGHS>
Analog V-SYNC <TPGVS>
Digital H-SYNC <TPDHS> Digital V-SYNC <TPDVS>
NRS <TP2531,TP2561>
R-S&H OUT <TPR1> G-S&H OUT <TPG1>
B-S&H OUT <TPB1>
