Sanyo PLC-SW30 Service Manual

-43-
Control Port Functions
1OE IO_ENB I
2D0 D0 I
3D1 D1 I
4D2 D2 I
5D3 D3 I
6D4 D4 I
7D5 D5 I
8D6 D6 I
9D7 D7 I
10 GND GND -
11 CK ADD1_CS Output Port Chip Select Enable = L I
12 Q7 ON_3.3V 3.3V OFF at standby mode O
13 Q6 TURBO_C Strobe for Turbo (IC9401) O
14 Q5 SH_B_ST Strobe for B sample & hold (IC501) O
15 Q4 SH_G_ST Strobe for G sample & hold (IC531) O
16 Q3 SH_R_ST Strobe for R sample & hold (IC561) O
17 Q2 IRM_RS Reset for IC401 O
18 Q1 MCLK_SW Switch for MCLK O
19 Q0 FAN_SW Switch for FAN O
20 Vdd Power Supply +3.3V -
Pin No. Name Function I/O
● Output Expander (IC1802, TC74LCX574FT) Port Functions
1 OE1 IO_ENB 1 CS1 Enable = L (OE1 and OE2) I
2A1K11 KEY Scan Input I
3A2K12 KEY Scan Input I
4A3K13 KEY Scan Input I
5A4 OPTION1 Option Resistor 1 I
6A5 OPTION2 Option Resistor 2 I
7A6 OPTION3 Option Resistor 3 I
8A7 LAMP_ERR Lamp Error Input I
9A8 S_SW S-video Detection I
10 GND GND -
11 Y 8 D 7 O
12 Y7 D6 O
13 Y6 D5 O
14 Y5 D4 O
15 Y4 D3 O
16 Y3 D2 O
17 Y2 D1 O
18 Y1 D0 O
19 OE2 IO_ENB 2 Enable = L (OE1 and OE2) I
20 Vdd Power Supply +3.3V -
Pin No. Name Function I/O
● Input Expander (IC1811, TC74LCX541FT) Port Functions

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
