Sanyo PLC-SW30 Service Manual

MP3-SW3000
-65-
Mechanical Parts List
1 610 308 3032 ASSY,BUTTON-MP3A
2 610 308 2646 ASSY,STAND LEG-MP3A
3 610 289 1812 BADGE V MARK S-MK6A
4 610 308 3124 BUTTON SEESAW-MP3A
5 610 308 2660 CABINET TOP-MP3A
6 610 308 2677 CABINET FRONT MP3A
7 610 308 2707 CABINET BOTTOM-MP3A
8 610 308 3223 CAP BUTTON SELECT-MP3A
9 610 308 2769 COVER LAMP-MP3A
10 610 311 0875 COVER LENS SHEET-MP3A
11 610 308 2790 DEC RC F-MP3A
12 610 308 3315 DEC RING-MP3A
13 610 308 3322 DEC LED-MP3A
14 610 308 2806 DEC AV SHEET-MP3A
15 610 308 2981 PANEL AV-MP3A
16 610 311 4521 SPACER BOTTOM C-MP3A
17 610 311 1025 SPACER FRONT MP3A
18 645 047 8031 BADGE,SANYO*26.2X5.7L26.0
21 610 308 2721 CAP LNS-MP3A
22 610 308 2776 COVER, POWER BTM-MP3A
23 610 308 3230 COVER, DUCT PBS-MP3A
24 610 308 3261 COVER, DUCT PNL A-MP3A
25 610 309 1815 COVER LAMP BST-MP3A
26 610 309 2195 COVER, DUCT PNL B-MP3A
27 610 308 3308 COVER POWER TOP-MP3A
28 610 311 4804 COVER BST SHEET-MP3A
29 610 311 0912 DEC LEG-MP3A
30 610 308 3490 MOUNTING FN-MP3A
31 610 308 3513 MOUNTING LMP FAN-MP3A
32 610 308 3520 PANEL NET S-MP3A
33 610 308 3537 PANEL NET F-MP3A
34 610 308 3544 PANEL NET B-MP3A
35 610 308 3551 PANEL NET PBS-MP3A
36 610 311 0998 SPACER OPT LMP MP3A
37 610 308 3636 SPACER SHEET-POWER MP3A
38 610 311 1032 SPACER LEG MP3A
39 610 311 2596 SPACER TEMPB SW-MP3A
40 610 311 4866 SPACER POWERMP3A
41 610 311 5153 SPACER BST-MP3A
51 411 025 6500 SCR S-TPG BIN 3X8
52 411 001 8801 SCR BIN 3X6
53 411 031 9304 SCR BIN 3X8
61 610 311 0073 ASSY,LCD PNL/PRISM-MP3A
62 645 061 9229 LENS,PROJECTION
63 645 061 9205 ASSY,OPTICAL
(Including Key No.64-69)
64 645 061 9496 POLARIZED GLASS(IN/G)
65 645 061 9502 POLARIZED GLASS(IN/B)
66 645 065 2530 LENS CONDENSER(R)
67 645 065 2547 LENS INTEGRATOR(IN)
68 645 065 2554 LENS INTEGRATOR(OUT)
69 645 065 2561 PRISM(PBS)
70 610 308 3803 OPTICAL LP-MP3A
OPTICAL PARTS
SCREWS-CHASSIS-
SCREWS-CABINET-
CHASSIS PARTS
CABINET PARTS
Key No. Part No. Description Key No. Part No. Description

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
