Sanyo PLC-XE33

-23-
● : Adjustment necessary ❍: Check necessary
Adjustments after Parts Replacement
Adjustments
Disassembly / Replaced Parts
LCD/
Prism Ass’y
Condenser
Lens (OUT)
Relay
Lens (OUT)
Condensor Glass Polarized Glass
Power
Board
Main
Board
G B
Optical
Adjustments
Contrast Adjustment
G-Contrast adjustment
❍ ●
B-Contrast adjustment
❍
● ●
Condenser lens adjustment
❍ ●
Relay lens-out adjustment
❍
●
Electrical Adjustments
Panel type check and setting
● ●
Fan control adjustment
● ●
Black Level adjustment
●
Auto calibration adjustment [PC]
●
Auto calibration adjustment
[Component]
●
Auto calibration adjustment
[Video]
●
Common center adjustment
● ●
50% white adjustment [PC]
● ●
White balance adjustment [PC]
❍ ❍
50% white adjustment [Video]
● ●
White balance adjustment
[Video]
❍ ❍
Keystone offset adjustment
●
Color shading correction adjust-
ment
❍ ❍
Caution:
Don't unplug the AC Cord without pressing the power button in the serving.
