Sanyo PLC-XL51A Service Manual

Mechanical Parts List
KV7-XL51A00
- 124 -
Key. No. Part No. Description
CABINET & CHASSIS PARTS
M01 610 347 8326 CABINET TOP-KM3AB
M02 610 347 5318 CABINET BOTTOM-KM3AB
M03 610 336 2595 CAP FOCUS LEVER-KM3A
M04 610 347 8845 COVER ,LP SERVICE-KM3AB
M06 610 335 7041 DEC INLAY LED-KM3A
M07 610 335 7027 DEC INLAY RC F-KM3A
M08 910 295 3085 DEC LEG-MW6A
M09 610 348 1197 DEC AV SHEET-KV7AE
M10 610 335 4057 FILTER BASE-KM3A
M11 610 341 0234 HOLDER AV-KV7A
M12 610 348 1203 PANEL AV-KV7AE
M13 610 338 4108 PIPE RC-KM3A
M14 610 336 2472 BUTTON-KM3A
M15 610 336 7729 ASSY,STAND PLATE-KM3A
M16 610 337 1559 CAP STAND LEG-KM3A
M17 610 337 1597 STAND LEG-KM3A
M18 610 337 1511 DEC STAND LEG-KM3A
M20 610 340 5421 DEC INLAY MCI LED-KV7A
M51 610 335 7294 BUSH-KM3A
M52 610 334 4348 HOLDER POWER PWB BTM-KM6AC
M54 610 336 2601 HOLDER TRIGGER BOX-KM3A
M55 610 336 7156 HOLDER T SW-KM3A
M56 610 335 4200 MOUNTING DUCT BTM-KM3A
M57 610 341 2634 MOUNTING DUCT TOP A-KV7A
M58 610 335 4101 MOUNTING DUCT EXH-KM3A
M59 610 338 1800 SPACER SHEET TMP SW-KM3A
M60 610 338 3897 SPACER SHEET AC PWB-KM3A
M61 610 336 8399 SPACER SHEET#POW T TOP-KM3A
M62 610 336 8290 SPACER SHEET#POW T BTM-KM3A
M63 610 336 8573 SPACER SHEET FAN-KM3A
M64 610 336 9457 SPACER SHEET AC-KM3A
M65 610 336 9402 SPACER SHEET AC T-KM3A
M66 610 331 1692 OPTICAL BASE BTM-KM6A
M67 610 331 1715 OPTICAL BASE TOP A-KM6A
M68 610 331 1722 OPTICAL BASE TOP B-KM6A
M69 645 094 5908 DAMPER,BUSH(DIA12*H9)
M70 610 340 5384 MOUNTING MCI-KV7A
M71 610 341 0210 MOUNTING DUCT TOP B-KV7A
M72 610 341 0203 HOLDER POL IN GB-KV7A
M73 610 349 7037 SPACER SHEET TMP SW-KV7AE
SCREWS
S01 411 189 7207 SCR S-TPG BIN 3X8
S02 411 214 2900 SCR S-TPG PAN 3X6
S03 411 189 8600 SCR BIN 3X8
S04 411 216 8603 SCR FLT 4X12
S05 411 216 8108 SCR S-TPG PAN 3X35
S07 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5
S08 412 077 5701 SPECIAL SCREW-3.0X10V
S09 312 069 7105 SPECIAL SCREW V
OPTICAL PARTS DIRECTORY
L01 610 341 3006 ASSY,PNL/PSM-KV7A
L02R 645 097 6711 POLARIZED GLASS(IN/R)
L02G 645 098 5461 ASSY,POLARIZED GLASS(G)
L02B 645 098 2156 ASSY,POLARIZED GLASS
L03 945 088 7797 LENS,INTEGRATOR(IN)
L04 645 098 8820 LENS,INTEGRATOR(OUT)NC*
L05 645 095 9851 LENS,CONDENSER(OUT)NC
L06 645 095 9868 LENS,CONDENSER(G)NC
L07 945 088 7841 LENS,CONDENSER(B)
L08 945 088 7858 LENS,CONDENSER(R)
L09 945 088 7865 LENS,RELAY(IN)
L10 945 088 7872 LENS,RELAY(OUT)
L11 645 102 2431 LENS,PROJECTION
(Including Key No. L11-1)
L11-1 645 099 2346 OPTICAL FILTER (B270)
L12 945 088 7889 MIRROR(B)
L13 945 088 7896 MIRROR(R)
L14 645 092 9892 PRISM(PBS)
L15 945 088 7902 DICHROIC MIRROR (B)
L16 945 088 7919 DICHROIC MIRROR (G)
PACKING MATERIALS
610 338 9455 CUSHION SPACER BTM-KM3A
610 348 1159 CARTON CASE-KV7AE
610 336 8207 CUSHION SPACER-KM3A
610 336 8382 CUSHION A-KM3A
610 336 8474 CUSHION B-KM3A
645 096 4015 POLY BAG-0750X0600*NC*R8P
610 340 6121 IND POLYE COVER PR4-PD4AA
ACCESSORIES
OWNER'S MANUAL
610 344 4413 CD-ROM(NETWORK V&C5)
610 347 9347 CD-ROM,OWNERS MANUAL-KV7AE
610 347 9118 SETUP INST MANUAL-KV7AE
REMOTE CONTROL
645 098 5881 ASSY,REMOCON CXZY
910 321 4482 RC-BATTERY LID-CXTJ
MISCELLANEOUS
910 314 8985 LABEL,PIN CODE-MY7A
610 347 9385 COMPL,FERRITE CORE-KV7AE
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
AC CORD
! (US) 945 064 6363 CORD,POWER-3.0MK,US
! (EU) 945 054 1156 CORD,POWER-3.0MK
! (UK) 945 054 1149 CORD,POWER-3.138MK
SERVICE TOOL
610 343 5596 CD-ROM,PJ SVC TOOL V420
