- 68 -
Service Adjustment
Group/
Item
Item Name Function Initial Range Note
4 Disp Line 1064 0 ~ 4095
7 Overscan Not used - 0 - 255
8 VSBEG Not used - 0 - 15
Group 553 RGB Video (1080P - 24)
0 Total Dots 2750 0 ~ 4095
1 Disp Dots 1878 0 ~ 4095
2 H Back Porch 214 0 ~ 4095
3 V Back Porch 46 0 ~ 4095
4 Disp Line 1070 0 ~ 4095
7 Overscan Not used - 0 - 255
8 VSBEG Not used - 0 - 15
Group 560 HDCP (480P)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1% steps)
- 0 - 255
8 VSBEG - 0 - 15
Group 561 HDCP (575P)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1% steps
) - 0 - 255
8 VSBEG - 0 - 15
Group 562 HDCP (720P-60)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1% steps)
- -
8 VSBEG - 0 - 15
Group 563 HDCP (720P-50)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1% steps)
- 0 - 255
8 VSBEG - 0 - 15
Group 564 HDCP (1080i-60)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1% steps)
- 0 - 255
8 VSBEG - 0 - 15
Group 565 HDCP (1080i-50)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1% steps
) - 0 - 255
8 VSBEG - 0 - 15
Group 566 HDCP (1035i)
7 Over Scan
Over Scan Rate (0 ~ 25.5% at 0.1% steps)
- 0 - 255
8 VSBEG - 0 - 15
