Pin No. Name Function Name Function I/O
172 COMPONENT CR Component Video signal I
258 ANALOG RGB B1 Analog RBG I
82 ANALOG RGB R1 Analog RBG I
260 ANALOG RGB G1 Analog RBG I
262 VIDEO VIDEO I
263 GSYNC I
409 YSYNC I
86 ANALOG RGB SCART_CV H1-IN I
264 S-VIDEO S_Y I
265 S-VIDEO S_CHROMA I
344 ON_15.5V_PW 15.5V Power drive Power ON : H O
413 LAMP BLAST_AC Power control, Power ON : H O
182 SIGNAL CABLE_SW Long cable switch O
89 LAMP LAMPDC_ON_SW Lamp control, Power ON : H O
267 SIGNAL S-SW S-video input switch I
474 I/O WAKEUP For I/O Expabder I
183 I/O XRESET I/O Expander reset O
90 I/O XSTBYEN Stanby mode enable/disenable O
268 SIGNAL MONIT_OUT Monitor out/Computer switch Monitor Out : H O
346 LED PW_POWER_LED_EX POWER LED Drive, ON : H O
91 LED PW_READY_LED_EX READY LED Drive, ON : H O
184 LED PW_TEMP_LED_EX TEMP LED Drive, ON : H O
269 LED PW_LAMP_LED_EX LAMP LED Drive, ON : H O
94 LED PW_FILTER_LED_EX FILTER LED Drive, on : h O
92 POWER DC_ON_PW IIC Bus control O
185 LAMP LAMP_DET Power control , Power ON : H I
347 STB_FPGA I
273 STANDBY MCU_STAT I
189 STANDBY PW_MASTER_SDI O
420 STANDBY PW_MASTER_SCK O
97 STANDBY PW_MASTER_SD0 I
208 Signal SDA2 IIC Bus SDA2 O
290 Signal SCL2 IIC Bus SCL2 O
Scaler I/O Port Functions (PW190) Continue
To Next Page
