-101-
Parts Location Diagrams
KA8-XM15000 / KA8-XM150L00
KZ5-XM10000 / KZ5-XM100L00
Filter box assembly
Power box assembly
A1890
FILTER SW BOARD
FN901
M26
AA600
POWER BOARD
M01
M16
S901
M21
M23
M22
M06
M07
A1880
AMF SENSOR BOARD
M901
A901
BALLAST BOARD
M29
M30
M28
M27
M31

Table of Contents

Other manuals for Sanyo PLC-XM100L

Preview: Owner's Manual
Owner's Manual149 pages
Preview: Network Manual
Network Manual60 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sanyo PLC-XM100L and is the answer not in the manual?

Sanyo PLC-XM100L Specifications

General IconGeneral
Vertical scan range48 - 100 Hz
Horizontal scan range15 - 100 kHz
Projection technologyLCD
Contrast ratio (typical)1000:1
Projector native resolutionXGA (1024x768)
Lamp typeNSH
Lamp power330 W
Light source typeLamp
Service life of light source2000 h
Service life of light source (economic mode)3000 h
Analog signal format systemNTSC, PAL, SECAM
S-Video inputs quantity1
Dimensions (WxDxH)489.5 x 371.1 x 164 mm
Noise level38 dB
Power consumption (standby)0.6 W
Power consumption (typical)400 W
Power consumption (economy mode)338 W
Weight and Dimensions IconWeight and Dimensions
Weight8900 g
