Sanyo PLC-XM100L Service Manual

-82-
Troubleshooting
Error Error Code
Error Infomation
(See Powe Failure Detection System)
Error Code
Error Infomation
(See Powe Failure Detection System)
Normal 0 -
Power Failure
1000 AD, 3.3V 1017 FILTER, 12V
1001 KS, 3.3V 1018 AV, S-6V
1002 KS, 2.5V
1019 FN904, 13V
1003 KS, 1.8V 1020 FN902, 13V
1004 GAMMA, 3.3V 1021 FN901, 13V
1005 GAMMA, 2.5V 1022 FN905, 13V
1006 GAMMA, 1.8V 1023 FN906&7&8, 13V
1007 DVI, 5V 1024 FN903, 13V
1008 DVI, 3.3V 1025 FN909&10&11, 13V
1009 DVI, 1.2V 1026 AUDIO AMP, 12V
1010 MAIN, S3.3V 1027 SWFPGA, 1.2V
1011 GAMMA, 15.5V 1028 MAIN, S5V
1012 PJNET, 5V 1029 MAIN, 5V
1013 LENS, 9V 1030 LAN, 3.3V
1014 LENS, 15V 1031 FILTER, DET
1015 MAIN, 6V 1032 MOTOR, TIMEOUT
1016 AUDIO SW, 12V
Temperature Error
2000 Sensor A detects abnormal temperature. (IC1692-ROOM)
2001 Sensor A fails measurement. (IC1692)
2100
Sensor B detects abnormal temperature. (IC1816-LAMP)
2101
Sensor B fails measurement. (IC1816)
2102
Sensors B-A temperature error.
2200
Sensor C detects abnormal temperature. (IC1814-PANEL)
2201
Sensor C fails measurement. (IC1814)
2202
Sensors C-A temperature error.
Lamp Error
3000 Lamp1 fails on
3001 Lamp1 goes out
3002
Communication Error on Lamp1
System Error 4000
FPGASW, CONFIG
Shutter Error 5000
SHUTTER, ERROR
Filter Error 6000 Filter clogged
Error Log
This projector provides the error history log function. To
check the logs, you need to enter the service mode and
select Group No. "220" and Item No. "0" to "49". The error
code is displayed on the Data column. The description of
the error code is listed on the table below.
* How to enter the service mode and select the group, item
and data value, see "Service Adjustment Menu Opera-
tion".
Group
No.
Item
No.
Data
(Error Code)
220 0
1
2
3
:
:
49
✻
<- Latest Error
✻
✻
✻
:
:
✻
How to reset the Error Log
1. Enter the Service Mode, and select Group No. "220" and Item No. "50".
2 The history log will be reset when the Data Value is set to "10". The value automatically returns to "0".
* How to enter the service mode and select the group, item and data value, see "Service Adjustment Menu Operation".

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
