Sanyo PLC-XM100L Service Manual

-109-
KA8-XM15000 / KA8-XM150L00
KZ5-XM10000 / KZ5-XM100L00
Mechanical Parts List
L03 645 101 1565 LENS,INTEGRATOR(OUT)
L04 645 101 1596 LENS,CONDENSER(OUT)
L05 645 101 1602 LENS,CONDENSER(R)
L06 645 101 1619 LENS,CONDENSER(G)
L07 645 101 1626 LENS,RELAY(IN)
L08 645 101 1633 LENS,RELAY(OUT)
L09 645 101 6553 LENS,PROJECTION-MOUNT
L10 645 101 8113 MIRROR(B)
L11 645 101 8120 MIRROR(R)
L12 645 101 8106 PRISM(PBS)
L13 645 101 6034 POLARIZED GLASS(IN/R)
L14 645 101 6041 POLARIZED GLASS(IN/G)
L15 645 101 6058 POLARIZED GLASS(IN/B)
L16 645 101 6027 DICHROIC MIRROR (B)
L17 645 101 8137 DICHROIC MIRROR (G)
L18 645 101 1053 ASSY,LENS,PROJECTION
(PLC-XM150/PLC-XM100 only)
* There are 2 type of LCD Panel/Prism Assy. Check which type of LCD
Panel/Prism Assy is used. How to check the type, see the item "Optical
Parts Disassembly".
SERVICE TOOLS
610 343 5596 CD-ROM,PJ SVC TOOL V420
Key No. Part No. Description
Key No. Part No. Description

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
