Sanyo PLC-XM100L Service Manual

Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
-144-
KA8-XM15000 / KA8-XM150L00
KZ5-XM10000 / KZ5-XM100L00
408 063 7507 ZENER DIODE MM3Z6V2B
D854 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D855 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D856 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D857 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D8801 307 209 7513 LED SML-210YT T86 L
D8902 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D9001 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D9002 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D9003 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D9004 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
MISCELLANEOUS
FB5801 945 041 1978 INDUCTOR,330 OHM
AU2802 945 082 0466 UNIT,REMOCON RECEIVER
K11A 952 001 8601 SOCKET,D-SUB 15P
K11B 645 101 8632 SOCKET,DVI 24P
K14A 952 001 8571 SOCKET,D-SUB 15P
K38A 945 053 4936 PLUG,D-SUB 9P
K9602 645 093 6760 TRANS,PULSE
SC1021 945 076 3503 SURGE-ABSORBER
SC1022 945 076 3503 SURGE-ABSORBER
SC1023 945 076 3503 SURGE-ABSORBER
SC3801 945 076 3503 SURGE-ABSORBER
SW301 945 026 2792 SWITCH,PUSH 1P-1TX1
SW302 945 026 2792 SWITCH,PUSH 1P-1TX1
X1351 945 088 7179 OSC,CRYSTAL 27.0MHZ
X2202 945 076 2407 OSC,CRYSTAL 25.000MHZ
X2331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X4801 645 092 8857 OSC,CRYSTAL 48MHZ
X5201 945 076 5194 OSC,CRYSTAL 79.991883MHZ
X8001 945 088 7179 OSC,CRYSTAL 27.0MHZ
X8802 945 083 7556 OSC,CRYSTAL 25.0MHZ
X9885 945 060 9900 OSC,CERAMIC 8.00MHZ
A1600 655 003 1044 ASSY,PWB,SENSOR C KA8AL
CAPACITOR
C1814 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
RESISTOR
R1825 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R1826 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
A1800 655 003 1037 ASSY,PWB, SENSOR A KA8AL
CAPACITOR
C1691 303 281 2415 CERAMIC 0.22U K 16V
303 364 5913 CERAMIC 0.22U K 16V
RESISTOR
R1691 301 224 8814 MT-GLAZE 100 JA 1/16W
R1692 301 224 8814 MT-GLAZE 100 JA 1/16W
R1693 301 224 8814 MT-GLAZE 100 JA 1/16W
A1880 655 003 1020 ASSY,PWB,AMF SENSOR KA8AL
CAPACITOR
C1816 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
RESISTOR
R1811 301 255 9217 MT-GLAZE 6.2K JA 1/10W
R1812 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R1813 301 256 6512 MT-GLAZE 68 JA 1/10W
DIODE
D1811 645 098 0428 UNIT,PHOTOINTERRUPTER
A1890 655 003 1013 ASSY,PWB,FILTER SW KA8AL
MISCELLANEOUS
SW1891 945 063 5176 SWITCH,PUSH 2P-2TX3
A8730 655 003 1006 ASSY,PWB,ID CONNECT KA8AL
RESISTOR
R8738 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
COIL
L8731 945 086 6037 IMPEDANCE,330 OHM P
L8732 945 086 6037 IMPEDANCE,330 OHM P
L8733 945 086 6037 IMPEDANCE,330 OHM P
L8734 945 086 6037 IMPEDANCE,330 OHM P
L8737 945 086 6037 IMPEDANCE,330 OHM P
A2000 655 003 0979 ASSY,PWB,A/V KA8AL
TRANSISTOR
Q2001 305 217 4913 TR RN1111 TE85L
Q2002 305 217 4913 TR RN1111 TE85L
Q2003 305 217 4913 TR RN1111 TE85L
Q3001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3002 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q5031 406 021 7804 TR 2SC4617
Q5032 406 021 7804 TR 2SC4617

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
