Sanyo PLC-XM100L Service Manual

-61-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
0 Total Dots 0 - 4095 2750
1 Disp Dots 0 - 4095 1874
2 H Back Porch 0 - 4095 256
3 V Back Porch 0 - 4095 52
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 140
6 Clamp Width 0 - 255 31
534 YCbCr (1080PSF-30)
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1875
2 H Back Porch 0 - 4095 249
3 V Back Porch 0 - 4095 90
4 Disp Line 0 - 4095 1013
5 Clamp 0 - 255 98
6 Clamp Width 0 - 255 31
535 YCbCr (1080PSF-25)
0 Total Dots 0 - 4095 2640
1 Disp Dots 0 - 4095 1875
2 H Back Porch 0 - 4095 249
3 V Back Porch 0 - 4095 90
4 Disp Line 0 - 4095 1013
5 Clamp 0 - 255 98
6 Clamp Width 0 - 255 31
536 YCbCr (1080PSF-24)
0 Total Dots 0 - 4095 2750
1 Disp Dots 0 - 4095 1878
2 H Back Porch 0 - 4095 254
3 V Back Porch 0 - 4095 50
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 178
6 Clamp Width 0 - 255 31
540 RGB Video (480i)
0 Total Dots 0 - 4095 1716
1 Disp Dots 0 - 4095 1346
2 H Back Porch 0 - 4095 323
3 V Back Porch 0 - 4095 50
4 Disp Line 0 - 4095 460
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 20
541 RGB Video (575i)
0 Total Dots 0 - 4095 1728
1 Disp Dots 0 - 4095 1318
2 H Back Porch 0 - 4095 366
3 V Back Porch 0 - 4095 64
4 Disp Line 0 - 4095 536
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 20
542 RGB Video (480P)
0 Total Dots 0 - 4095 1716
1 Disp Dots 0 - 4095 1368
2 H Back Porch 0 - 4095 281
3 V Back Porch 0 - 4095 56
4 Disp Line 0 - 4095 458
5 Clamp 0 - 255 70
6 Clamp Width 0 - 255 20
543 RGB Video (575P)
0 Total Dots 0 - 4095 1728
1 Disp Dots 0 - 4095 1360
2 H Back Porch 0 - 4095 300
3 V Back Porch 0 - 4095 73
4 Disp Line 0 - 4095 540
5 Clamp 0 - 255 70
6 Clamp Width 0 - 255 20

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
