Video Input
Image Adjustment
Press the MENU button to display the On-Screen Menu.
Use the Point ◄► buttons to move the red frame pointer
to the Image Adjust Menu icon.
1
2
Use the Point ▲▼ buttons to move the red frame
pointer to the desired item and then press the SELECT
button to display the adjustment dialog box. Use the
Point ◄► buttons to adjust the setting value.
Press the Point ◄ button to decrease the contrast; press the
Point ► button to increase the contrast (from 0 to 63).
Press the Point ◄ button to decrease the brightness; press
the Point ► button to increase the brightness (from 0 to 63).
Contrast
Brightness
Press the Point ◄ button to lighten red tone; press the Point
► button to deepen red tone (from 0 to 63).
White balance (Red)
Press the Point ◄ button to lighten green tone; press the
Point ► button to deepen green tone (from 0 to 63).
White balance (Green)
Press the Point ◄ button to lighten blue tone; press the
Point ► button to deepen blue tone (from 0 to 63).
White balance (Blue)
Use the Point ◄► buttons to select the desired Color temp.
level (High, Mid, Low, or XLow).
Color temp.
Press the Point ◄ button decrease the intensity of the color;
press the Point ►button increase the intensity of the color
(from 0 to 63).
Press the Point ◄► buttons to adjust the tint value to get a
proper color balance (from 0 to 63).
Color
Tint
Notes:
• When the White balance Red, Green, or Blue is adjusted,
the Color temp. level will change to “Adj.”.
• Tint cannot be selected when the video system is PAL,
SECAM, PAL-M, or PAL-N (p.38).
Use the Point ◄► buttons to
adjust the setting value.
Move the red frame
pointer to the desired
item and then press
the SELECT button.
Image Adjust Menu
Image Adjust Menu icon
