Sanyo PLC-XW55A Service Manual

Key No. Part No. Description Key No. Part No. Description
KR6-XW55A00, KP6-XW50A00
Electrical Parts List
-70-
L3634 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L401 301 253 3712 MT-GLAZE 0.000 ZA 1/4W
301 035 4111 MT-GLAZE 0.000 ZA 1/8W
L4811 645 092 3616 IMPEDANCE,22 OHM P
L4812 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L4813 645 092 3616 IMPEDANCE,22 OHM P
L4814 645 092 3616 IMPEDANCE,22 OHM P
L4891 645 092 3616 IMPEDANCE,22 OHM P
L4892 645 092 3616 IMPEDANCE,22 OHM P
L501 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L502 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5201 945 004 6644 INDUCTOR,220 OHM
652 002 3345 INDUCTOR,220 OHM P
L531 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5311 945 059 2264 INDUCTOR,4.7U M
L532 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5331 945 059 2264 INDUCTOR,4.7U M
L5332 945 032 8344 INDUCTOR,39U J
L5606 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5607 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5608 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5609 645 092 3616 IMPEDANCE,22 OHM P
L561 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5615 645 092 3616 IMPEDANCE,22 OHM P
L562 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5661 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5662 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L5701 945 041 1978 INDUCTOR,330 OHM
652 002 3260 INDUCTOR,330 OHM P
L7811 945 038 4579 INDUCTOR,33U M
L7861 945 038 4562 INDUCTOR,100U M
DIODE
D1351 307 254 2716 DIODE CMS16
307 201 2724 DIODE RB051L-40-TE25
D2002 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D2891 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D2892 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D3051 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3601 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3603 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3604 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3606 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3607 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3612 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3613 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3614 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3617 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3621 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3622 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3626 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D3627 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D4812 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D4813 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D5061 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D5062 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D5201 307 205 5216 DIODE RB521S-30-TE61
D5202 307 205 5216 DIODE RB521S-30-TE61
D5211 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D5212 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D5704 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D6801 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6802 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6803 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6804 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
