Sanyo PLC-XW55A Service Manual

Key No. Part No. Description Key No. Part No. Description
KR6-XW55A00, KP6-XW50A00
-71-
Electrical Parts List
D6831 407 256 6511 LED SML-212YT T86
D6832 307 203 7816 LED SML-210LT T86 M
D6833 307 222 4810 LED SML-521MUW T86
D6841 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D6842 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D6843 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D6844 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D7812 307 254 2716 DIODE CMS16
307 201 2724 DIODE RB051L-40-TE25
D7862 307 254 2716 DIODE CMS16
307 201 2724 DIODE RB051L-40-TE25
MISCELLANEOUS
IC301A 645 090 0655 CORE,FERRITE
K10A 952 001 8601 SOCKET,D-SUB 15P
K10B 952 001 8571 SOCKET,D-SUB 15P
K20A 952 001 8977 JACK,RCA-3
K30A 945 007 7457 JACK,PHONE D3.5
652 002 2003 JACK,PHONE D3.6
K30B 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
K40A 945 078 1613 SOCKET,DIN 8P
652 002 2713 SOCKET,DIN 8P
SC1031 945 076 3503 SURGE-ABSORBER
SC1041 945 076 3503 SURGE-ABSORBER
SC1081 945 076 3503 SURGE-ABSORBER
SC1091 945 076 3503 SURGE-ABSORBER
SC2031 945 076 3503 SURGE-ABSORBER
SC2041 945 076 3503 SURGE-ABSORBER
SC2051 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3011 945 076 3503 SURGE-ABSORBER
SC3051 945 076 3503 SURGE-ABSORBER
SC3061 945 076 3503 SURGE-ABSORBER
SC3081 945 076 3503 SURGE-ABSORBER
SC3082 945 076 3503 SURGE-ABSORBER
SW6801 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6802 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6803 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6804 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6806 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6807 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6808 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6811 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
X1331 945 088 7179 OSC,CRYSTAL 27.0MHZ
FOR CHASSIS NO. KR6-XW55A00
655 001 9059 ASSY,PWB,R/C KR6AD
FOR CHASSIS NO. KP6-XW50A00
655 001 9271 ASSY,PWB,R/C KP6AD
INTEGRATED CIRCUIT
IC8831 309 481 8615 IC LM76CHMX-5
CAPACITOR
C2901 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C2902 303 453 8719 CERAMIC 470P K 50V
303 453 9211 CERAMIC 470P K 50V
C2903 303 378 3110 CERAMIC 47U Z 6.3V
C8831 303 453 7019 CERAMIC 33P J 50V
303 453 9617 CERAMIC 33P J 50V
303 276 3113 CERAMIC 33P J 50V
C8832 303 453 7019 CERAMIC 33P J 50V
303 453 9617 CERAMIC 33P J 50V
303 276 3113 CERAMIC 33P J 50V
C8833 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
RESISTOR
R2901 301 225 1814 MT-GLAZE 47 JA 1/16W
R2903 301 224 8814 MT-GLAZE 100 JA 1/16W
R8831 301 225 8110 MT-GLAZE 10 JA 1/16W
R8832 301 225 8110 MT-GLAZE 10 JA 1/16W
R8833 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
MISCELLANEOUS
A2901 945 084 1997 UNIT,REMOCON RECEIVER
A2901A 610 332 6344 SPACER RC-KR6AC
655 001 9066 ASSY,PWB,POWER
TRANSISTOR
Q601 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q602 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q611 305 146 6405 TR 2SK2837
Q621 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q622 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
