Top Control
INPUT button
Video Input
Press the INPUT button on the top control or COMPUTER 1
button on the remote control to select Computer 1.
Before using INPUT or COMPUTER 1 buttons, select the
correct input source through Menu operation as described
below.
Use the MENU button to display the On-Screen Menu.
Press the Point 7 8 buttons to move the red frame
pointer to the Input Menu icon.
1
Computer
1
Input Menu
Use the Point ed buttons to move the red arrow
pointer to Computer 1 and then press the SELECT
button.
2
After the Source Select Menu appeared for Computer
1, move the pointer to RGB (Scart) and then press the
SELECT button.
3
Input Source Selection (RGB Scart 21-pin)
Direct Operation
Menu Operation
Move the pointer (red arrow)
to Computer 1 and press the
SELECT button.
Input Menu icon
Move the pointer to RGB (Scart)
and press the SELECT button.
Source Select Menu
Remote Control
COMPUTER 1 button
When the input source is coming from
video equipment connected to the
COMPUTER IN 1 terminal with a Scart-VGA
Cable (not supplied), select RGB (Scart).
RGB (Scart)
✔Note:
• Computer 2 is not displayed when the COMPUTER IN 2/
MONITOR OUT terminal is set as Monitor out (p.49).
• Computer 2 (COMPUTER IN 2/MONITOR OUT) can
accept only RGB signal.
• Wired and Wireless are for the Network function. See
owner’s manual “Network Set-up and Operation” .
*See Note at the bottom of this page.
38
INPUT button
Video
Computer 2*
Computer 1
Wireless
Wired
To Next Page
