9
Bottom
Back
w Top controls and Indicators
e Exhaust Vent
r
y
!1
!3
!2
CAUTION
Hot air is exhausted from the exhaust
vent. Do not put heat-sensitive objects
near this side.
w
t
e
Front
Part Names and Functions
i
u
CAUTION
The Infrared Remote Receiver sticks out
of the cabinet surface. If the Infrared
Remote Receiver is put on the wall
or floor directly, the Infrared Remote
Receiver may damage.
r Rear Leg
t Adjustable Feet
y Air Intake Vent
u Terminals and Connectors
i Power Cord Connector
o Focus Lever
!0 Projection Window
q
✽
✽Kensington Security Slot
This slot is for a Kensington lock used
to deter theft of the projector.
* Kensington is a registered trademark of ACCO Brands
Corporation.
✔Note:
Do not touch the projection window,
otherwise, the window may be soiled
and the image can be smudgy.
q Infrared Remote Receiver
!1 Speaker
!2 Battery Cover
!3 Lamp Cover
!4 Air Filter
o
!0
!4
