Sanyo XL51 - PLC XGA LCD Projector User Manual

Appendix
Terminal : Mini DIN 8-PIN
1
2
3
4
5
8
7
6
SERVICE PORT CONNECTOR
R X D
-----
-----
GND
RTS / CTS
GND
GND
Serial
1
2
3
4
5
6
7
8
COMPUTER INPUT / MONITOR OUTPUT TERMINAL (ANALOG)
Terminal : Analog RGB (Mini D-sub 15 pin)
5
1
2
3 4
10
96 7 8
15
14
13
11
12
Configurations of Terminals
Red Input / Output
Ground (Horiz.sync.)
Green Input / Output
-----
Blue Input / Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
5V / -----
Horiz. sync. Input/Output (Composite H/V sync.)
Ground (Vert.sync.)
DDC data / -----
Ground /
-----
Vert. sync.
DDC clock/ -----
9
13
10
12
11
14
15
T X D
Dimensions
Unit: inch (mm)
7.75 (196.8)
7.91 (201)
4.50 (114.3)
2.36 (60)
8.78 (223)
9.49 (241)
2.99 (76)
3.43 (87)
Lens center
Lens center
7.09 (180)
4.29 (109)
8.58 (218)
14.72 (374)
1.0°
1.0°
0.17 (4.2)
19.49 (495)
16.59 (421.5)
3.65 (92.8)
0.41 (10.5)
0.33 (8.5)
9.37 (238)
0.37 (9.5)
16.73 (425)
7.17 (182)
4.61 (117)
0.63 (16)
1.87 (47.5)
0.63 (16)
5.0 (127)
スタンド 取 り付 け 穴と
天吊り用穴４カ所共通
PLC-XL51
Screw Holes for Ceiling Mount
Screw: M4
Depth: 0.393 (10.0)
74
RX –
TX +
TX –
RX +
2
3
4
87654321
5
6
7
8
1
LAN TERMINAL
-----
-----
----------
