Web Interface - Inputs (3300 only)
Code Blue:
Code Blue is a special-purpose count up designed for use in hospitals and other medical facilities. This
function overrides the control panel LED settings. The lights are green while the timer is running and red
when the timer has been paused.
When an input programmed with Code Blue is activated for the first time, the count up starts.
When the input is activated a second time, the count up pauses. If the input is activated a third time, the
count up will resume.
When the input is activated for a period longer than three seconds, the count up resets to zero and the
display goes back to showing the time.
If a button programmed with the Start/Stop function is pressed while Code Blue is running, the count up
will pause. If Start/Stop is pressed again, the count up will resume.
On countdown complete, close: This option allows a user to choose how many seconds a relay will be
closed for.
At end of Countdown, go to: This option allows a user to choose between having the clock display the
time or start a count up when a countdown completes.
Once all of the Input settings are chosen, click the ‘Submit’ button to store the selected options or, when
all the tabs have been programmed, click the ‘submit’ button located at the bottom to store all changes..
Flash Zeros at end of Countdown: This option allows a user to command the clock to have the zeros on
the clock display blink on and off to indicate the end of a countdown.
