Plug the cord of the AC adapter into the balance
as follows:
– Use the DC jack (14) for balances with a weighing
capacity of <10 kg
– Use the DC jack (14) for balances with a weighing
capacity of ≥10 kg
Insert the right-angle plug into the jack as shown in the
diagram on the left; then tighten the screw.
Then insert the plug of the AC adapter into a wall outlet (mains).
Voltage Selection
(does not apply to balances with a weighing capacity of ≥12 kg)
You can select the voltage only if you use our portable power supply (6971172)
that has a European-type plug (rounded prongs).
Safety Precautions
The AC adapter rated to Class 2 can be plugged into any wall outlet without
requiring any additional safety precautions. The ground terminal is connected to
the balance housing, which can be additionally grounded for operation.
The data interface is also electrically connected to the balance housing (ground).
Information on Radio Frequency Interference
Note:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct the
interference at his own expense. Changes or modifications not expressly
approved by Sartorius AG could void the user’s authority to operate the equipment.
17
