General Specifications
Type of interface Serial point-to-point connector
Operating mode Asynchronous, full-duplex
Standard V28, RS-232C specification
Handshake*) 2-wire interface: via software (XON/XOFF)
4-wire interface: via hardware handshake lines with
Clear To Send (CTS) and Data Terminal Ready (DTR)
Transmission rates*) 150; 300; 600; 1,200; 2,400; 4,800;
9,600;19,200 baud
Character coding 7-bit ASCII
Parity*) Mark, space, odd, even
Synchronization 1 start bit;1or 2 stop bits*)
Data output format*) 16 or 22 characters
of the balance
Character format*) – 1 start bit
– 7-bit ASCII
– 1 parity bit
– 1 or 2 stop bits
*) = c an b e chan ged by the user
55
