Model BP 8100-0CE BP 6100-0CE BP 2100-0CE BP 8-0CE
Type BA BC 200, BA BC 200, BA BC 200, BA BC 200,
BD BC 200 BD BC 200 BD BC 200 BD BC 200
Accuracy class KKKK
Maximum capacity Max* g 8,100 6,100 2,100 8,100
Scale interval d* g 0.1 0.1 0.1 1.0
Verification scale interval e* g 1.0 1.0 0.1 1.0
Minimum capacity Min* g 5.0 5.0 5.0 50
Tare range (by subtraction) g –8,100 –6,100 –2,100 –8,100
Range of use according to
Directive No. 90/384/EEC* g 5–8,100 5–6,100 5–2,100 50–8,100
Response time (average) s ≤1 ≤1 ≤1 ≤1
Allowable ambient operating temperature °C 0 ...+40
Operating temperature range °C +10...+30
Pan size mm 210 x180 210 x180 180 x 180 210 x 180
Dimensions (WxDxH) mm 238 x297x81
Net weight, approx. kg 4.9
Selectable weight units g, kg
Power requirements V~ Via AC adapter: STNG 6, 230 VAC or 115 VAC,
–20% ... +15% (IP 20 protection)
Frequency Hz 48–63
Power consumption (average) VA 16 maximum; 8 average
Hours of operation with fully charged
YRB 05 Z external battery pack, approx. h 25 25 25 25
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, odd;
transmission rates: 150...19,200 baud;
1or 2 stop bits; software/hardware handshake
Standard features/equipment supplied:
AC adapter; varies acc. to country x x x x
Built-in, motorized calibration weight x x x x
Level indicator x x x x
* = EC Directive No. 90/384/EEC for Non-Automatic Weighing Instruments applicable in the
EC/EU Member States
82
