External Calibration
Set the following parameters:
SETUP - BAL.SCAL.- CAL.Just. - Cal.Ext. (Code 1.1. 9. 1)
The required calibration weight is configured at the factory (see “Specifications").
Step Key (or instruction) Display
1. Tare balance
w 0.0 g
2. Start adjustment routine
Q Cal.Ext.
Once you store the zero point
- 5000.0 g
the display prompts for the required
calibration weight (flashing display)
3. Apply the prompted calibration
5000.0 g
weight (in this example 5000 g).
Weight too low:
a minus sign “-" is shown
Weight too high:
a plus sign “+" is shown
The display stops flashing as soon as
the weight value is within the defined
limit.
4. Calibration/adjustment executed;
Cal.end
then the calibration weight
is displayed
+ 5000.0 g
5. Remove the calibration weight
0.0 g
