26 Cubis MSE Operating Instructions
Getting Started
t Attach the display and control unit to the electronics module:
Reattach the two retaining screws�
Open the slot for the connection cable on the electronics module:
t Remove the screws from beneath the electronics module and detach the plate�
Connect the display and control unit to the electronics module:
t Plug in the connection cable�
t Then reattach the plate to the slot�
t Slide the cable that sticks out into the cable channel�
Preparing Below-Cell Weighing
Balances with a readability of ≥ 0,01 mg:
A port for a below-cell weighing hook is located on the bottom of the balance�
Analysis and Precision Balances with a Weighing Range up to 15 kg:
1. Remove the hook for below-cell weighing from the clip on the bottom of the
balance�
1

Sartorius MSE20201S Specifications

General

Readability	0.1 g
Repeatability (Std. Dev.)	0.1 g
Pan Size	400 mm x 300 mm
Power Supply	AC Adapter
Display	LCD
Stabilization Time (typical)	1.5 s
Operating Temperature	+10°C to +30°C
Linearity	0.2 g
Calibration	External
Interface	RS-232
